K3V140

Kawasaki K3V140 hydraulic pump specifications

The Kawasaki K3V140 hydraulic pump is a variable displacement axial piston pump with a swash plate designed for use in mobile machinery, including excavators, loaders and other construction equipment.

Technical specifications of the Kawasaki K3V140 hydraulic pump:

Type: Swash plate axial piston pump

• Displacement: 140 cm³/rev
• Nominal pressure: 34.3 MPa (343 bar)
• Maximum pressure: 39.2 MPa (392 bar)
• Maximum rotation speed (self-priming): 2160 rpm
• Weight: about 86 kg
• Application: excavators, construction machinery, agricultural machinery, etc.

Design features of the Kawasaki K3V140 hydraulic pump

• Configurations: single-section, tandem and parallel
• Types of regulators: mechanical, hydraulic, electro-hydraulic, load-compensated (LS), pressure and combined
• Additional options: presence or absence of PTO (power take-off shaft)

The Kawasaki K3V140 hydraulic pump has the following advantages::

• High reliability: durability and wear resistance
• Compact: easy to install in limited space
• Flexibility: adaptability to different operating conditions thanks to a wide choice of configurations and regulators
• High performance: stable oil supply even under high loads

Hydraulic pump cross number: 31N8-10020, 31N8-10011, 31N8-10050, 31E9-03010, 31E5-03010, 31N8-10010, 31E2-03010, 11E9-1501, 11E5-1501, 14531591, 14641331, 14575661, 14524052, 7220-00601, 1042-02181, 2401-9233B

Installed in the model:

• DAEWOO-DOOSAN: S290LC-V
• HYUNDAI: R280LC R290LC R290LC-3 R290LC-7, R300LC-7 R320LC
• VOLVO: EC290B
• XCMG: XE335

The company "Aspect Plus" offers a wide range of spare parts for repairing the Kawasaki K3V140 hydraulic pump.
