Sort By:
Most Viewed
Model: 5640
Spare part: Flange Kawasaki 331/19618 AFM
Part number: 331/19618
Cross-Number: 1031086, 332/..
223.18 $
excl. VAT 223.18 $
Other parts:
Other parts
Most Viewed
Model: 6619
Spare part: Gear Hub Kawasaki K3V63 SPINPARTS Part number: Cross-Number: Use in: Kawasaki K3V63 Use ..
71.21 $
excl. VAT 71.21 $
Couplings:
Couplings
Most Viewed
Model: 17350
Spare part: Gear pump Kawasaki 20/950961 SKS
Part number: 20/950961
Cross-Number: 332/C1080,..
216.00 $
excl. VAT 216.00 $
PTO, gear pumps, regulators:
PTO, gear pumps, regulators
Most Viewed
Model: 4006
Spare part: Gear pump Kawasaki 2902440 HANDOK Part number: 2902440 Cross-Number: 2902440-1671A, 2902..
179.14 $
excl. VAT 179.14 $
PTO, gear pumps, regulators:
PTO, gear pumps, regulators
Most Viewed
Model: 4004
Spare part: Gear pump Kawasaki VOE14534034 HANDOK Part number: VOE14534034 Cross-Number: Use in: Ple..
166.88 $
excl. VAT 166.88 $
PTO, gear pumps, regulators:
PTO, gear pumps, regulators
Most Viewed
Model: 17901
Spare part: Hydraulic Pump assembly K3V63DTP-1R9R-9C2J Kawasaki K3V63 SKS Part number: K3V63DTP-1R9R..
2,866.30 $
excl. VAT 2,866.30 $
Hydraulic pumps and motors:
Hydraulic pumps and motors
Most Viewed
Model: 5919
Spare part: Hydraulic Pump Cover (rear) Kawasaki 20/950613H HANDOK Part number: 20/950613H Cross-Num..
63.05 $
excl. VAT 63.05 $
Hydraulic housing parts:
Hydraulic housing parts
Most Viewed
Model: 13458
Spare part: Hydraulic Pump Head Cover (block) Kawasaki SA8230-09270 HANDOK Part number: SA8230-09270..
32.44 $
excl. VAT 32.44 $
Hydraulic housing parts:
Hydraulic housing parts
Most Viewed
Model: 5034
Spare part: Hydraulic Pump Head Cover (block) Kawasaki XJBN-00087 HANDOK Part number: XJBN-00087 Cro..
33.43 $
excl. VAT 33.43 $
Hydraulic housing parts:
Hydraulic housing parts
Most Viewed
Model: 5559
Spare part: Needle Bearing Kawasaki 0924003 NTN
Part number: 0924003
Cross-Number: XJBN-0042..
31.25 $
excl. VAT 31.25 $
Oil seals, bearings, gears of hydraulic pumps and motors:
Oil seals, bearings, gears of hydraulic pumps and motors
Most Viewed
Model: 12582
Spare part: Oil Seal Kawasaki 5I-8769 AFM
Part number: 5I-8769
Cross-Number: 03505511, 20/95..
12.50 $
excl. VAT 12.50 $
Oil seals and belts:
Oil seals and belts
Most Viewed
Model: 2698
Spare part: Piston shoe Kawasaki 0928006 HANDOK
Part number: 0928006
Cross-Number: XJBN-0043..
13.85 $
excl. VAT 13.85 $
Plates, pistons, bushings for hydraulic systems:
Plates, pistons, bushings for hydraulic systems
Most Viewed
Model: 6039
Spare part: Piston shoe Kawasaki 0928006 SKS Part number: 0928006 Cross-Number: 0928006, XJBN-00437,..
15.56 $
excl. VAT 15.56 $
Plates, pistons, bushings for hydraulic systems:
Plates, pistons, bushings for hydraulic systems
Most Viewed
Model: 17654
Spare part: Pressure Sensor Hitachi 4436271 SKS
Part number: 4436271
Cross-Number: 4703324, ..
45.56 $
excl. VAT 45.56 $
Sensors, switches, gauges, glow plugs:
Sensors, switches, gauges, glow plugs
Most Viewed
Model: 7214
Spare part: PTO box assembly Kawasaki 334/E2948 HANDOK
Part number: 334/E2948
Cross-Number:
..
335.63 $
excl. VAT 335.63 $
PTO, gear pumps, regulators:
PTO, gear pumps, regulators
Kawasaki K3V63 hydraulic pump specifications
The Kawasaki K3V63 hydraulic pump is a variable displacement axial piston pump with a swash plate designed for use in mobile machinery, including excavators, loaders and other construction equipment.
Technical specifications of the Kawasaki K3V63 hydraulic pump:
- Type: Swash plate axial piston pump
- Displacement: 63 cm3/rev
- Nominal pressure: 34.3 MPa (350 bar)
- Maximum pressure: 39.2 MPa (392 bar)
- Maximum rotation speed: up to 2650 rpm (self-priming)
- Maximum speed: up to 3250 rpm
- Weight: about 50 kg
- Dimensions: approximately 480 × 305 × 230 mm
- Applications: excavators, loaders, cranes, tractors, combines, drilling rigs, hydraulic hammers
Design features of the Kawasaki K3V63 hydraulic pump
- Configurations: single-section, tandem (two-section) and parallel
- Types of regulators: mechanical, hydraulic, electro-hydraulic, load-compensated (LS), pressure and combined
- Additional options: presence or absence of PTO (power take-off shaft)
The Kawasaki K3V63 hydraulic pump has the following advantages::
- High reliability: durability and wear resistance
- Compact: easy to install in limited space
- Flexibility: adaptability to different operating conditions thanks to a wide choice of configurations and regulators
- High performance: stable oil supply even under high loads
Hydraulic pump cross number: 20/925329, 20/925329R, 20/925461, 20/925506, 20/925516, 20/925517, 20/925517R, 20/925753, 20/925764, 332/J1352, 333/J2892, 333/J3129, JNJ0138, JLJ0231, KNJ1025, KNJ1817, KLJ0001, KLJ0317, 20/925577, 333/J3309, 333/J3306, 333/J3310, 332/J0050, 20/925461, 2401-9186A, 2401-9236, 2401-9236A, 2401-9236B, 2401-9041P, 2401-9113P, K1051796, 31N3-10010, 31N3-10011, 31N3-10050, 31N3-10060, 31N4-15011, 31N4-15012, 31N4-15030, XJBN-00848, XJBN-00927, XJBN-00928, XJBN-01028, 31E6-03010, 31EG-10010 11E6-1501, VOE14531858, SA1142-00660, 1042-02202L, 1142-05460, YB10V00005F3 2437U412F1 2437U188F1 KMJ2937 KLJ0638 KNJ3021X, KNJ3021, KNJ3023, KLJ0653, KLJ0653X, KMJ2939, KMJ11920, KNJ11920, KLJ0638XB, KLJ0638, K1024107A, 11E3-1501, 2437U412F4, YX10V00001F1, 133-6766, 155-9078, 158-7765, 129-7968, 5I-8750, 137-3640, 129-7988, 111-9978, 7I-0149, 133-6729, 155-9079, 5I-8749, 5I-8761, 095-1718, 095-0882, 095-1209, 5I-8760, 095-1783, 095-1584, 5I-8766, 095-1698, 5I-8770, 5I-8767, 095-1575, 095-1717, 5I-8772, 5I-8774, 5I-8778, 7I-1282, 5I-8782, 5I-8768, 5I-8773, 5I-8750, 5I-8762, 5I-8818, 8T-0269, 8T-6759, 5I-8763, 129-7976, 5I-8765, 5I-8757, 127-5976, 5I-8816, 133-6731, 133-6730, 096-0014, 127-5975, 5I-8755, 5I-8759, 5I-8781, 095-1711, 6V-5683, 5I-8754, 6V-5200, 5I-8769, 096-3150, 095-1585, 5I-8775, 102-2562, 095-1574, 095-1777, 5I-8771, 5H-1472, 095-1713, VOE14567022, VOE14508516, VOE14604488, SA8230-32220, SA8230-09231, SA8230-28260, SA8230-28280, SA8230-25430, VOE14511629, SA8230-14520, SA8230-09220, VOE14508524, SA8230-09380, SA8230-09420, SA8230-09620, SA8230-32180, SA8230-09270, VOE14567020, SA8230-08920, SA8230-09390, SA8230-25840, SA9415-11021, SA8230-26050, VOE14560637, SA8230-09730, VOE14508528, VOE14511631, SA8230-09410, VOE14528251, VOE14534033, VOE14534032, VOE14534031, VOE14533604, VOE14534029, VOE14534028, VOE14528250, VOE14518818, VOE14880816, SA9566-20300, SA8230-25620, SA9541-01035, SA8230-26400, SA7223-00660, SA8230-25450, SA8230-26780, VOE14555218
Installed in the model:
- DAEWOO-DOOSAN: DX140LC-3, DX160LC-3, S130LC-2, S130-2, S130-III, S130LC-V, DX140LC, S140LC-V, S150LC-V, S155LC-V, S140W-V, S160W-V, DH120W-2
- HYUNDAI: R110-7, R110-7A, R120W R130W-3, R130LC-3, R140LC-7, R140W-7, R140W-7S, R140LC-3, R140LC-7, R150LC-7, R160LC-3, R150W-7, R1400LC-7, R1300W, R1300W-3,
- JCB: JS110, JS115, JS130, JS130 AUTO, JS130LC, JS130W, JS145 JS145HD,JS145LC, JS145W, JS145W-T2, JS160, JS160W, JS160W-T2, JS180, JS180 AUTO
- VOLVO: EC140B LC, EC140C, EW130, EC130
- SANY: SY135
- SAMSUNG: MX135W, MX132LC, SE130W-2, MX135W-3
- KOBELCO E195B E165 E175 SK90 SK100 SK115 SK120 SK120-3 SK130 SK140 SK150
- CASE CX130 CX135 CX160
- CATERPILLAR 311-A 311B 311B 312-A 312B L 312B 312-A 312B L 315-A L 315-A 315B FM L 315B L 317B LN 317B L 317 N 317-A N 317-A 318B N 318B
The company "Aspect Plus" offers a wide range of spare parts for repairing the Kawasaki K3V63 hydraulic pump.
